Overview
You have played with the electronics but now it's time to get serious, this is a absolute must have if you're planning to take your electronic developments to a new level.
Specifications
| Brand | Minleaf & LONG WEI |
| Model | K3010D |
| Input Voltage | AC 110/220V±10% 50~60Hz |
| Input Current (at 220VAC, at full load) | 0.6A |
| Output Voltage Range | 0~30V |
| Output Current Range | 0~10A |
| Load Regulation | <=0.3%+5mV |
| Ripple | <=10mVrms |
| Voltage Display Accuracy | ±0.5% |
| Current Display Accuracy | ±0.5% |
| Display accuracy | ±0.01 |
| Efficiency | >85% |
| Dimension | Approx.20*7*15.1cm |
| Operating Ambient | -10℃ ~ 60℃ / 30%RH~ 90% RH |
| Plug | EU Plug |
